<B>Chipset: </B> AMD X570

<B>Rozměrový formát: </B> ATX Form Factor (305 mm x 244 mm) <B>Podpora pro procesory: </B> 3rd and 2nd Gen AMD Ryzen™/3rd, 2nd and 1st Gen AMD Ryzen™ with Radeon™ <B>Patice procesoru: </B> AM4

<B>Pozice na paměti: </B> 4x DDR4 DIMM <B>Podpora pro paměti: </B> 5100(O.C)/4800(O.C.)/4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133 MHz Un-buffered Memory <B>Max.velikost operační paměti: </B> 128 GB <B>Podpora pro paměti typu: </B> DDR4 *Dual Channel Memory Architecture

<B>Grafická karta: </B> *Integrated Graphics Processor (na základě procesorů 3., 2. a 1. generace AMD s Radeon Grpahics)

<B>Multi GPU: </B>AMD 2-Way CrossFireX™ Technology

<B>Zvuková karta: </B> *Realtek® ALC S1200A 8-Channel High Definition Audio CODEC

<B>Síťová karta: </B> *Intel® I225-V 2.5Gb Ethernet *Intel® Wi-Fi 6 AX200 *Bluetooth v5.1

<B>Rozšiřující sloty: </B> *<B>3rd Gen AMD Ryzen™ Processors </B> *1x PCIe 4.0 x16 (x16 mode) *<B>2nd Gen AMD Ryzen™ and 3rd Gen AMD Ryzen™ with Radeon™ Graphics Processors </B> *1x PCIe 3.0 x16 (x16 mode) *<B>2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors </B> *1x PCIe 3.0/2.0 x16 (x8 mode) *<B>AMD X570 chipset </B> *1x PCIe 4.0 x16 (max at x4 mode) *2x PCIe 4.0 x1

<B>RAID řadič: </B> 0, 1, 10

<B>SATA: </B> *8x SATA 6Gb/s ports

<B>M.2: </B> *1x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) storage devices support *1x M.2 Socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) storage devices support

<B>USB: </B> *<B>zadní USB porty ( celkem 7 )</B> *3x USB 3.2 Gen 2 port(s)(2 x Type-A +1 x Type-C) *4x USB 3.2 Gen 1 port(s)(4 x Type-A) *<B>přední USB porty ( celkem 7 )</B> *1x USB 3.2 Gen 2 front panel connector port(s)(1 x Type-C) *2x USB 3.1 Gen 1 port(s)(2 x Type-A) *4x USB 2.0 port(s)(4 x Type-A)

<B>Interní porty: </B> *1x CPU Fan connector(s) *1x CPU OPT Fan connector(s) *3x Chassis Fan connector(s) *1x AIO_PUMP connector *2x Aura RGB Strip Header(s) *1x Addressable Gen 2 header(s) *1x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin, Type-C) *2x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) *1x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode) *1x M.2 Socket 3 with M Key, type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE mode) *1x SPI TPM header *8x SATA 6Gb/s connector(s) *1x 24-pin EATX Power connector(s) *1x 8-pin ATX 12V Power connector(s) *1x 4-pin ATX 12V Power connector(s) *1x Front panel audio connector(s) (AAFP) *1x System panel(s) *1x Clear CMOS jumper(s) *1x COM port header *1x USB 3.2 Gen 1 (up to 5Gbps) connector support additional 2 USB ports

<B>Externí porty: </B> *1x PS/2 keyboard/mouse combo port(s) *1x DisplayPort *1x HDMI *1x LAN (RJ45) port(s) *1x Optical S/PDIF out *5x Audio jack(s) *1x BIOS FlashBack™ Button(s) *1x ASUS Wi-Fi Module *4x USB 3.2 Gen 1 (up to 5Gbps) ports *3x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A + USB Type-C)

<B>Obsah balení: </B> *User's manual *I/O Shield *2x SATA 6Gb/s cable(s) *1x M.2 Screw Package *1x Supporting DVD *1x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) *1x TUF GAMING Sticker *1x TUF Certification card(s) *1x M.2 Rubber Package(s)

<B>BIOS: </B>256 Mb Flash ROM, UEFI AMI BIOS

<B>Stránka výrobce: </B> https://www.asus.com/Motherboards/TUF-GAMING-X570-PRO-WI-FI https://www.asus.com/microsite/motherboard/ASUS-motherboards-Win11-ready/ https://www.asus.com/support/FAQ/1046215
